Dimensions 220 x 220 x 47 mm (8.7 x 8.7 x 1.9″)
UniFi Application Suite
✓ Protect
✓ Access
Managed Cameras (15) HD (8) 2K (6) 4K
Managed Access Hubs 50
Storage Capacity (1) 3.5″ drive bay
✓ Data Protection
✓ Vantage Point
Networking Interface (1) GbE RJ45 uplink port (6) GbE PoE RJ45 downlink ports (1) HDMI port (Viewport)
Form Factor Compact Desktop
Mounting Wall, Din rail mount (Included)
✓ Door Access Support
UniFi Application Suite
✓ Protect
✓ Access
Managed Cameras (15) HD (8) 2K (6) 4K
Managed Access Hubs 50
Storage Capacity (1) 3.5″ drive bay
✓ Data Protection
✓ Vantage Point
Networking Interface (1) GbE RJ45 uplink port (6) GbE PoE RJ45 downlink ports (1) HDMI port (Viewport)
Form Factor Compact Desktop
Mounting Wall, Din rail mount (Included)
✓ Door Access Support
Hard Drive Capacity (1) 3.5″ HDD support
Max. Power Budget for Drives 11W
Max. Power Consumption 9W
Power Method Universal AC input, 100-240VAC, 1.5A Max, 50/60 Hz
Power Supply AC/DC, Internal, 60W
PoE Budget 40W
Max. PoE Wattage per Port by PSE
PoE 15.4W
Voltage Range PoE Mode 44–57V
Processor Quad-core ARM® Cortex®-A55 at 1.7 GHz
Memory 4 GB
Management Ethernet Bluetooth
Display 1.14″ screen
Weight 1.04 kg (2.3 lb)
Enclosure Material Polycarbonate
Mount Material Polycarbonate
✓ Ethernet
✓ PoE
Ambient Operating Temperature 0 to 40° C (32 to 104° F)
Ambient Operating Humidity 5 to 95% noncondensing
✓ NDAA Compliant
Certifications FCC, IC, CE, Electrical Safety, SRRC, Anatel: 06781-25-08356
