Dimensions Device: 160.6 x 51.7 x 35.1 mm (6.3 x 2 x 1.4″) Wall mount: 159.3 x 50.3 x 17.5 mm (6.3 x 1.9 x 0.7″) Wedge: 161.1 x 52.1 x 25.7 mm (6.3 x 2.1 x 1″) On-wall mount: 161.1 x 52.1 x 25.75 mm (6.3 x 2.1 x 1″)
IR Night Vision 6 m (20 ft)
✓ Smart Detections (People, Vehicles, Animals)
Resolution FHD
Field of View Main camera: H: 138°, V: 114°, D: 155° (LDC On) Main camera: H: 160°, V: 117°, D: 160° (LDC Off) Package camera: H: 97.5°, V: 79.4°, D: 118.2°
Audio Two-way audio
Weatherproofing IPX4
Mounting Wall, wedge (Included) Gang box, junction box (Optional)
UniFi Application Suite
✓ Protect
Networking Interface GbE RJ45 port
Video
Max. Frame Rate 30 FPS
Resolution Main camera: 2MP 1600 x 1200 (4:3) Package camera: 2MP 1600 x 1200 (4:3)
Optics
Sensor Main camera: 5MP CMOS Package camera: 8MP CMOS
Lens Fixed focal length
Night Mode Built-in IR LED illumination and IR cut filter
Max. Power Consumption 7W
Supported Voltage Range 37—57V DC
Power Method PoE
Processor Quad-core Arm® Cortex®-A53 based chip
Weight Device: 264 g (9.3 oz) Wall mount: 56 g (2 oz) Wedge: 33 g (1.2 oz) On-wall mount: 53 g (1.9 oz)
Enclosure Material Polycarbonate, aluminum alloy
Mount Material Flat wall mount: aluminum alloy 20° wedge mount: polycarbonate
Button (1) Ring button (1) Factory-reset
Ambient Operating Temperature -30 to 40º C (-22 to 104º F)
Ambient Operating Humidity 0 to 90% noncondensing
✓ NDAA Compliant
Certifications CE, FCC, IC, SRRC
Mobile app
UniFi Protect iOS™ and Android™
Dimensions Device: Ø62 x 54 mm (Ø2.5 x 2.1″) In-wall mount: Ø89 x 63.1 mm (Ø3.5 x 2.5″) On-wall Mount: Ø62 x 20.2 mm (Ø2.5 x 0.8″)
Weight Device: 158 g (5.6 oz) In-wall mount: 91 g (3.2 oz) On-wall mount: 28 g (1 oz)
Enclosure Material Polycarbonate, aluminum alloy
Mount Material Polycarbonate, zinc alloy
Networking Interface 10/100 MbE port
Power Method PoE
Supported Voltage Range 44—57V DC
Max. Power Consumption 3W
LED R/G/B/W
Buttons (1) Factory-reset
Speaker Yes
Buzzer Yes
Ambient Operating Temperature 0 to 40° C (32 to 104° F)
Ambient Operating Humidity 10 to 90% noncondensing
Certifications CE, FCC, IC
✓ NDAA Compliant
