Dimensions 169.7 x 112.2 x 32.2 mm (6.7 x 4.4 x 1.3″)
Coverage Area 90 m² (1,000 ft²)
Max. Client Count 300+
Mounting Wall (Wall Power Socket Included)
Power Method Universal AC input, 100—240V AC, 0.3A max., 50/60 Hz
Coverage Area 90 m² (1,000 ft²)
Max. Client Count 300+
Mounting Wall (Wall Power Socket Included)
Power Method Universal AC input, 100—240V AC, 0.3A max., 50/60 Hz
MIMO
5 GHz 4 x 4
2.4 GHz 2 x 2
Max. Data Rate
5 GHz 1.7 Gbps
2.4 GHz 300 Mbps
Antenna Gain
5 GHz 5 dBi
2.4 GHz 4.5 dBi
Max. TX Power
5 GHz 30 dBm
2.4 GHz 24.8 dBm
Max. BSSIDs 8 per Radio
Supported Data Rates
802.11n 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
✓ Wireless Meshing
✓ Band Steering
✓ 802.11v BSS Transition Management
✓ 802.11r Fast Roaming
✓ 802.11k Radio Resource Management (RRM)
✓ Zero-Wait DFS
✓ Advanced Radio Management
✓ Passpoint (Hotspot 2.0)
✓ Captive Hotspot Portal
✓ Custom Branding Landing Page
✓ Voucher Authentication
✓ Payment-Based Authentication
✓ External Portal Server Support
✓ Password Authentication
✓ Guest Network Isolation
✓ RADIUS over TLS (RadSec)
✓ Dynamic RADIUS-assigned VLAN
Max. Power Consumption 11.5W
Supported Voltage Range 100—240V AC
Weight 260 g (9.2 oz)
Management Bluetooth
✓ NDAA Compliant
Certifications FCC, IC
Ambient Operating Temperature -10 to 60° C (14 to 140° F)
Ambient Operating Humidity 5 to 95% noncondensing
Supported Voltage Range 100—240V AC
Weight 260 g (9.2 oz)
Management Bluetooth
✓ NDAA Compliant
Certifications FCC, IC
Ambient Operating Temperature -10 to 60° C (14 to 140° F)
Ambient Operating Humidity 5 to 95% noncondensing
Application Requirements
UniFi Network Version 6.0.45 and later
