Dimensions Ø197 x 35 mm (Ø7.8 x 1.4″)
WiFi Standard WiFi 6
Spatial Streams 6
Coverage Area 140 m² (1,500 ft²)
Max. Client Count 350+
Uplink GbE
Mounting Ceiling, Wall (Pro Mount Included)
Weatherproofing IP54
Power Method PoE
WiFi Standard WiFi 6
Spatial Streams 6
Coverage Area 140 m² (1,500 ft²)
Max. Client Count 350+
Uplink GbE
Mounting Ceiling, Wall (Pro Mount Included)
Weatherproofing IP54
Power Method PoE
MIMO
5 GHz 4 x 4 (DL/UL MU-MIMO)
2.4 GHz 2 x 2 (UL MU-MIMO)
Max. Data Rate
5 GHz 4.8 Gbps (BW160)
2.4 GHz 573.5 Mbps (BW40)
Antenna Gain
5 GHz 6 dBi
2.4 GHz 4 dBi
Max. TX Power
5 GHz 26 dBm
2.4 GHz 22 dBm
Max. BSSIDs 8 per Radio
Supported Data Rates
802.11ax (WiFi 6) 7.3 Mbps to 4.8 Gbps (MCS0 – MCS11 NSS1/2/3/4, HE 20/40/80/160)
802.11ac (WiFi 5) 6.5 Mbps to 3.4 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11n 6.5 Mbps to 600 Mbps (MCS0 – MCS31, HT 20/40)
5 GHz 4 x 4 (DL/UL MU-MIMO)
2.4 GHz 2 x 2 (UL MU-MIMO)
Max. Data Rate
5 GHz 4.8 Gbps (BW160)
2.4 GHz 573.5 Mbps (BW40)
Antenna Gain
5 GHz 6 dBi
2.4 GHz 4 dBi
Max. TX Power
5 GHz 26 dBm
2.4 GHz 22 dBm
Max. BSSIDs 8 per Radio
Supported Data Rates
802.11ax (WiFi 6) 7.3 Mbps to 4.8 Gbps (MCS0 – MCS11 NSS1/2/3/4, HE 20/40/80/160)
802.11ac (WiFi 5) 6.5 Mbps to 3.4 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11n 6.5 Mbps to 600 Mbps (MCS0 – MCS31, HT 20/40)
✓ Wireless Meshing
✓ Band Steering
✓ 802.11v BSS Transition Management
✓ 802.11r Fast Roaming
✓ 802.11k Radio Resource Management (RRM)
✓ Advanced Radio Management
✓ Passpoint (Hotspot 2.0)
Captive Hotspot Portal
✓ Custom Branding Landing Page
✓ Voucher Authentication
✓ Payment-Based Authentication
✓ External Portal Server Support
✓ Password Authentication
✓ Guest Network Isolation
✓ Private Pre-Shared Key (PPSK)
✓ WiFi Speed Limiting
✓ Client Device Isolation
✓ WiFi Schedules
✓ RADIUS over TLS (RadSec)
✓ Dynamic RADIUS-assigned VLAN
✓ Band Steering
✓ 802.11v BSS Transition Management
✓ 802.11r Fast Roaming
✓ 802.11k Radio Resource Management (RRM)
✓ Advanced Radio Management
✓ Passpoint (Hotspot 2.0)
Captive Hotspot Portal
✓ Custom Branding Landing Page
✓ Voucher Authentication
✓ Payment-Based Authentication
✓ External Portal Server Support
✓ Password Authentication
✓ Guest Network Isolation
✓ Private Pre-Shared Key (PPSK)
✓ WiFi Speed Limiting
✓ Client Device Isolation
✓ WiFi Schedules
✓ RADIUS over TLS (RadSec)
✓ Dynamic RADIUS-assigned VLAN
Max. Power Consumption 13W
Supported Voltage Range 44—57V DC
Networking Interface (1) GbE RJ45 port
Weight Device: 580 g (1.3 lb) With mount: 720 g (1.6 lb)
Management Ethernet Bluetooth
Enclosure Material Polycarbonate
Mount Material Stainless steel (SUS304)
LEDs System White/Blue
Channel Bandwidth HT 20/40, VHT 20/40/80/160, HE 20/40/80/160 (MHz)
✓ NDAA Compliant
Certifications CE, FCC, IC, Anatel, SRRC
Operating Frequency US/CA: 2400 – 2472 MHz U-NII-1: 5150 – 5250 MHz U-NII-2A: 5250 – 5350 MHz U-NII-2C: 5470 – 5725 MHz U-NII-3: 5725 – 5850 MHz Worldwide: 2400 – 2483.5 MHz 5150 – 5725 MHz
Ambient Operating Temperature -30 to 60° C (-22 to 140° F)
Ambient Operating Humidity 5 to 95% noncondensing
Supported Voltage Range 44—57V DC
Networking Interface (1) GbE RJ45 port
Weight Device: 580 g (1.3 lb) With mount: 720 g (1.6 lb)
Management Ethernet Bluetooth
Enclosure Material Polycarbonate
Mount Material Stainless steel (SUS304)
LEDs System White/Blue
Channel Bandwidth HT 20/40, VHT 20/40/80/160, HE 20/40/80/160 (MHz)
✓ NDAA Compliant
Certifications CE, FCC, IC, Anatel, SRRC
Operating Frequency US/CA: 2400 – 2472 MHz U-NII-1: 5150 – 5250 MHz U-NII-2A: 5250 – 5350 MHz U-NII-2C: 5470 – 5725 MHz U-NII-3: 5725 – 5850 MHz Worldwide: 2400 – 2483.5 MHz 5150 – 5725 MHz
Ambient Operating Temperature -30 to 60° C (-22 to 140° F)
Ambient Operating Humidity 5 to 95% noncondensing
Application Requirements
UniFi Network Version 6.0.45 and later
