Dimensions Ø90 x 71.2 mm (Ø3.5 x 2.8″)
IR Night Vision 30 m (98 ft)
✓ Smart Detections (People, Vehicles, Animals)
Resolution 2K
Field of View H: 102.4°, V: 54.9°, D: 120.6°
Audio Microphone
Weatherproofing IP66
Tamper Resistance IK04
Mounting Wall, ceiling mount (Included) Junction box, arm mount (Optional)
IR Night Vision 30 m (98 ft)
✓ Smart Detections (People, Vehicles, Animals)
Resolution 2K
Field of View H: 102.4°, V: 54.9°, D: 120.6°
Audio Microphone
Weatherproofing IP66
Tamper Resistance IK04
Mounting Wall, ceiling mount (Included) Junction box, arm mount (Optional)
Networking Interface 10/100 MbE RJ45 port
Video
Image Settings Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay
Max. Frame Rate 30 FPS
Resolution 4MP 2688 x 1512 (16:9)
Optics
Sensor 1/2.4″ CMOS
Lens Fixed focal length
Night Mode Built-in IR LED illumination and IR cut filter
Video
Image Settings Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay
Max. Frame Rate 30 FPS
Resolution 4MP 2688 x 1512 (16:9)
Optics
Sensor 1/2.4″ CMOS
Lens Fixed focal length
Night Mode Built-in IR LED illumination and IR cut filter
Max. Power Consumption 4W
Supported Voltage Range 37—57V DC
Power Method PoE
Processor Dual-core Arm® Cortex®-A7 based chip
Weight 330 g (11.6 oz)
Enclosure Material Aluminum alloy, UV-stabilized polycarbonate
Mount Material Polycarbonate
Button (1) Factory-reset
Cable
Cable Connector Type RJ45
Cable Diameter 5 mm (0.2″)
Cable Length 30 cm (1 ft)
Jacket Material Polycarbonate
Jacket Enclosure Dimensions Ø20 x 70.6 mm (0.8 x 2.8″)
Jacket Enclosure Material Thermoplastic elastomer, polycarbonate, silicone rubber
Ambient Operating Temperature -30 to 50° C (-22 to 122° F)
Ambient Operating Humidity 0 to 90% noncondensing
✓ NDAA Compliant
Certifications CE, FCC, IC
Supported Voltage Range 37—57V DC
Power Method PoE
Processor Dual-core Arm® Cortex®-A7 based chip
Weight 330 g (11.6 oz)
Enclosure Material Aluminum alloy, UV-stabilized polycarbonate
Mount Material Polycarbonate
Button (1) Factory-reset
Cable
Cable Connector Type RJ45
Cable Diameter 5 mm (0.2″)
Cable Length 30 cm (1 ft)
Jacket Material Polycarbonate
Jacket Enclosure Dimensions Ø20 x 70.6 mm (0.8 x 2.8″)
Jacket Enclosure Material Thermoplastic elastomer, polycarbonate, silicone rubber
Ambient Operating Temperature -30 to 50° C (-22 to 122° F)
Ambient Operating Humidity 0 to 90% noncondensing
✓ NDAA Compliant
Certifications CE, FCC, IC
