Ubiquiti Flex Mini 2.5G 5-Port Switch [USW-Flex-2.5G-5]

Dimensions 117.1 x 90 x 21.2 mm (4.6 x 3.5 x 0.8″)
Port Layout 2.5 GbE RJ45 5 (2.5G/1G/100M/10M)
Form Factor Compact desktop

Switching Capacity 25 Gbps
Total Non-Blocking Throughput 12.5 Gbps
Forwarding Rate 19 Mpps
Supported VLANs 256
MAC Address Table Size 4,000

✓ STP & RSTP
✓ Egress Rate Limit
✓ Flow Control
✓ Storm Control
✓ Multicast & Broadcast Rate Limiting
✓ Port Isolation
✓ Port Mirroring
✓ Jumbo Frames
✓ Loop Protection

Max. Power Consumption 5W (AC/DC input) 6.4W (PoE input)
Power Method (1) USB Type-C, 5V DC, 1A (1) PoE
Power Input Method USB Input PoE
Power Supply AC/DC, external, 5W
Supported Voltage Range 4.8—5.2V DC/USB 44V—57V PoE
Management Ethernet
Weight 206 g (7.3 oz)
Enclosure Material Polycarbonate
Ambient Operating Temperature -20 to 45° C (-4 to 113° F)
Ambient Operating Humidity 10 to 90% noncondensing
✓ NDAA Compliant
Certifications CE, FCC, IC, Anatel
