Dimensions 126 x 45 x 37.45 mm (4.9 x 1.8 x 4.5″)
✓NFC Card & Keyfob Access
✓ Mobile Unlock
Maximum User Count 3,000
✓ NDAA Compliant
UL 294 Level
Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I
✓ Tamper Switch
Weatherproofing IP55
Weight 140 g (4.9 oz)
Enclosure Material Polycarbonate, aluminum alloy
Mount Material Stainless steel
Mounting Wall mount, gang box mount (Included) Junction box (Optional)
Indoor and Outdoor Use Yes
Ambient Operating Temperature -30 to 40° C (-22 to 104° F)
Ambient Operating Humidity 5 to 90% noncondensing
Networking Interface (1) 10/100 MbE RJ45 port
Connectivity BLE 4.2 Ethernet
Power Method PoE+ UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU
Max. Power Consumption 18W
Supported Voltage Range 44—57V DC
ESD/EMP Protection Air: ±8kV, contact: ± 4kV
Powered Output Relay Lock: 12V DC, 1A
✓ Speaker
LEDs R/G/B/W Learn More
Button (1) Factory-reset
NFC Frequency 13.56 Mhz
NFC Read Range < 50 mm (1.95”)
NFC Technology ISO 14443A, 14443B, 15693 NFC Tag 1,2,3,4,5 MIFARE Classic MIFARE Plus Mifare Ultralight MIFARE DESFire PoE Cabling Requirements
Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm² ) for patch cords; 24 AWG (0.21 mm² ) for horizontal or riser cable.
UL 294 Statement
Compliance with IEEE 802.3 specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.
CAN/ULC-60839-11-1 Grade Grade assignment: I
Certifications CE, FCC, IC, Anatel: 06371-24-08356, SRRC, UL 294, CAN/ULC-60839-11-1
Document number, and issue date and/or revision level UA-Ultra, V01
Management Application Access
Software Information The software version can be checked at https://unifi.ui.com
