Coverage Area 185 m² (2,000 ft²)
Max. Client Count 250+
Uplink GbE
Mounting Wall, Pole (Mounts Included)
Weatherproofing IPX6
Power Method PoE
MIMO
5 GHz 2 x 2 (DL/UL MU MIMO)
2.4 GHz 2 x 2 (DL/UL MU-MIMO)
Max. Data Rate
5 GHz 2.4 Gbps (BW160)
2.4 GHz 573.5 Mbps (BW40)
Antenna Gain
5 GHz 8 dBi
2.4 GHz 8 dBi
Max. TX Power
5 GHz 27 dBm
2.4 GHz 22 dBm
Max. BSSIDs 8 per Radio
Supported Data Rates
802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160)
802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80/160)
802.11n 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
✓ Wireless Meshing
✓ Band Steering
✓ 802.11v BSS Transition Management
✓ 802.11r Fast Roaming
✓ 802.11k Radio Resource Management (RRM)
✓ Advanced Radio Management
✓ Passpoint (Hotspot 2.0)
✓ Captive Hotspot Portal
✓ Custom Branding Landing Page
✓ Voucher Authentication
✓ Payment-Based Authentication
✓ External Portal Server Support
✓ Password Authentication
✓ Guest Network Isolation
✓ Private Pre-Shared Key (PPSK)
✓ WiFi Speed Limiting
✓ Client Device Isolation
✓ WiFi Schedules
✓ RADIUS over TLS (RadSec)
✓ Dynamic RADIUS-assigned VLAN
Max. Power Consumption 9W
✓ Includes PoE Adapter
Supported Voltage Range 42.5—57V DC
Networking Interface (2) GbE RJ45 ports
Weight 819 g (1.8 lb)
Pole Mount Diameter 1–2.5″ (25–63.5 mm)
Management Ethernet WiFi
Enclosure Material UV-stabilized polycarbonate
Mount Material Aluminum alloy, steel
LEDs
System White/Blue
Channel Bandwidth HT 20/40, VHT 20/40/80/160, HE 20/40/80/160 (MHz)
✓ NDAA Compliant
Certifications CE, FCC, IC, Anatel: 06377-24-08356
Operating Frequency
US/CA: 2400 – 2472 MHz
U-NII-1: 5150 – 5250 MHz
U-NII-2A: 5250 – 5350 MHz
U-NII-2C: 5470 – 5725 MHz
U-NII-3: 5725 – 5850 MHz
Worldwide: 2400 – 2483.5 MHz / 5150 – 5725 MHz
Ambient Operating Temperature -30 to 60° C (-22 to 140° F)
Ambient Operating Humidity 5 to 95% noncondensing
