Dimensions 353 x 46 x 34.4 mm (13.9 x 1.8 x 1.4″)
WiFi Standard WiFi 5
Spatial Streams 4
Coverage Area 140 m² (1,500 ft²)
Max. Client Count 200+
Uplink GbE
Mounting Wall, Pole (Mounts Included)
Weatherproofing IPX4
Power Method PoE
MIMO
5 GHz
2 x 2 (DL MU-MIMO)
2.4 GHz
2 x 2 (DL MU-MIMO)
Max. Data Rate
5 GHz
867 Mbps (BW80)
2.4 GHz
300 Mbps (BW40)
Antenna Gain
5 GHz
4 dBi
2.4 GHz
3 dBi
Max. TX Power
5 GHz
20 dBm
2.4 GHz
20 dBm
Max. BSSIDs
8 per Radio
Supported Data Rates
802.11ac (WiFi 5)
6.5 Mbps to 867 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80)
802.11n
6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
Wireless Meshing
✓ Band Steering
✓ 802.11v BSS Transition Management
✓ 802.11r Fast Roaming
✓ 802.11k Radio Resource Management (RRM)
✓ Advanced Radio Management
✓ Passpoint (Hotspot 2.0)
✓ Captive Hotspot Portal
Custom Branding Landing Page
✓ Voucher Authentication
✓ Payment-Based Authentication
✓ External Portal Server Support
✓ Password Authentication
✓ Guest Network Isolation
✓ Private Pre-Shared Key (PPSK)
✓ WiFi Speed Limiting
✓ Client Device Isolation
✓ WiFi Schedules
✓ RADIUS over TLS (RadSec)
✓ Dynamic RADIUS-assigned VLAN
Max. Power Consumption 8.5W
✓ Includes PoE Adapter
Supported Voltage Range 44—57V DC
Networking Interface (1) GbE RJ45 port
Weight 152 g (5.4 oz)
Pole Mount Diameter 1–3″ (25–76 mm)
Management Ethernet Bluetooth
Enclosure Material Polycarbonate
Channel Bandwidth HT 20/40, VHT 20/40/80 (MHz)
✓ NDAA Compliant
Certifications CE, FCC, IC, UKCA, Anatel: 01769-18-08356
Operating Frequency US/CA: 2400 – 2472 MHz U-NII-1: 5150 – 5250 MHz U-NII-2A: 5250 – 5350 MHz U-NII-2C: 5470 – 5725 MHz U-NII-3: 5725 – 5850 MHz Worldwide: 2400 – 2483.5 MHz 5150 – 5725 MHz
Ambient Operating Temperature -30 to 70° C (-22 to 158° F)
Ambient Operating Humidity 5 to 95% noncondensing
Application Requirements
UniFi Network Version 6.0.45 and later
